Nordson Dage introduces Quadra

Nordson Dage introduces Quadra

The unbeatable Manual X-ray Inspection System

Nordson DAGE, the leader in X-ray inspection for the electronics industry is pleased to launch the NEW Quadra™ Series – our 4th generation, ultra-high resolution, off-line X-ray systems. With in-house, proprietary QuadraNT™ tube, Aspire FP™ detector, Gensys™ inspection software and QuadraGen™ power supply Nordson DAGE brings you the future of X-ray image resolution, reliability, performance and throughput. The Quadra™ Series offers the highest feature recognition and resolution X-ray systems not only within failure analysis laboratories but also within the production environment. It has been designed with the user in mind and offers unbeatable image quality in the shortest possible time.

Highest feature recognition at full power

The new Quadra™ 7 is equipped with two 4K UHD displays. That’s 8 million pixels utilizing the 50µm pixel pitch and 6.7MP image size of the Aspire FP™ detector. This offers up to 4 times the detail compared to standard systems and supports 68,000X total magnification. To learn more, visit the website: www.nordsondage.com/quadra

Design for electronics

Nordson DAGE believe in innovative solutions and going beyond the boundaries. As specialists in the complete design, development and production of X-ray systems for the electronics industry they uniquely control all the technology in the X-ray imaging chain.

Nordson Dage_Quadra2

Wide Range of Applications

  • Ball grid array (BGA)
  • Quad-flat no-leads (QFN)
  • Quad flat package (QFP)
  • Package on package (POP)
  • Printed circuit board/assembly (PCB/PCA)
  • Integrated circuits (IC)
  • Semiconductor packaging
  • Microelectromechanical systems (MEMS, MOEMS)
  • Power management integrated circuits (PMIC’s)/IGBT
  • Fan-out wafer level packages (FO-WLP)
  • 3D stacked packages
  • High performance memory
  • Connectors
  • Bottom termination components (BTC)
  • RF devices
  • Pad analysis
  • Cu-pillars
  • Micro-bumps
  • Plated thru holes (PTH)
  • Wire analysis
